Product Details:
Place of Origin: CHINA
Brand Name: KAMTAI
Certification: ISO
Model Number: KTRKF03
Payment & Shipping Terms:
Minimum Order Quantity: 100 PCS
Price: Negotiable
Packaging Details: PLYWOOD BOX AND PALLET
Delivery Time: 25 DAYS AFTER PAYMENT
Payment Terms: T/T, L/C, Western Union,Paypal
Supply Ability: 3000PCS/MONTH

High temperature refractory corundum mullite push plate for firing

Description
Material: Corundum Mullite Type: Push Plate
Color: White Size: 340*340*30mm
Max Using Temperature: 1600℃ Package: Wooden Box





1. Description

Introducing our premium corundum mullite push trays, the ultimate solution for high performance applications in demanding environments. These trays are engineered to withstand extreme temperatures while maintaining exceptional strength and durability.



2. Technical data

property cordierite mullite cordierite- mullite Mullite -- corundum
Al2O3 % ≥ 40 ≥ 65 ≥ 80 ≥ 92
Fe2O3 % ≤ 1.5 ≤ 1.5 ≤ 1.2 ≤ 0.5
density g/cm3 ≥2.0 ≥2.4 ≥2.6 ≥3.7
Thermal expansion 1000 C 2.30 5.0 6.50 7.8
Refractoriness C ≥ 1580 ≥1650 ≥ 1750 ≥ 1850
Thermal stability 1100 C--(cold water)times ≥ 70 ≥ 20 ≥ 10 ≥ 5
Working temperature ≤ 1250 ≤ 1350 ≤ 1450

≤ 1500







3.Product Feature


High temperature resistance

Made from premium corundum and mullite materials, our pusher trays offer excellent resistance to high temperatures, making them ideal for use in furnaces where conventional trays may fail. Designed to withstand temperatures in excess of 1600°C, these trays ensure your operations run smoothly without the risk of deformation or failure.

High strength

One of the standout features of our corundum-mullite pusher pallets is their impressively high strength. This feature not only increases their load-bearing capacity, but also their service life. Whether you are pushing heavy objects or handling abrasive materials, these pallets can withstand the rigors of industrial use, giving you peace of mind.

Longer service life

In addition to strength and high temperature resistance, our pusher trays also have a long service life, greatly reducing the need for frequent replacement. This long service life means lower operating costs and higher efficiency, allowing you to focus on what matters most - growing your business.


Application Scope


Long-term usage temperature of 1650℃, outstanding thermal shock resistance, high compressive strength, good elastic modulus, and an exceptionally long service life.


Meet Your Customized Needs


Corundum Mullite Push trays are more than just a product, they are an investment in quality and performance. Suitable for a variety of applications including the ceramic, glass and metal industries, these pallets are versatile enough to meet your specific needs.

Upgrade your production processes with our corundum mullite push rod trays and experience the difference that high-quality materials and expert engineering can make. Trust our commitment to excellence and let us help you achieve the best results in your operations.
