Heat Resistant Refractory Kiln Furniture Ceramic Fiber Blanket White Color

Heat Resistant Refractory Kiln Furniture Ceramic Fiber Blanket White Color
Heat Resistant Refractory Kiln Furniture Ceramic Fiber Blanket White Color

Large Image :  Heat Resistant Refractory Kiln Furniture Ceramic Fiber Blanket White Color

Product Details:
Place of Origin: CHINA
Brand Name: KAMTAI
Certification: SGS
Model Number: KTCB12
Payment & Shipping Terms:
Minimum Order Quantity: 10 Rolls
Price: Negotiable
Packaging Details: Carton box
Delivery Time: 25 days after payment
Payment Terms: Western Union, L/C, T/T, MoneyGram,Paypal
Supply Ability: 30000 Cubic Meter/Cubic Meters per Year

Heat Resistant Refractory Kiln Furniture Ceramic Fiber Blanket White Color

Description
Name: Heat Resistant 1260 Ceramic Fiber Blanket For Refractory Kiln Furniture Type: Ceramic Fiber
Using Temperature: 1260 Color: White
Width: 610mm Thickness: 25mm
High Light:

high temperature ceramic plates

,

alumina ceramic disc

Heat resistant 1260 ceramic fiber blanket for refractory kiln furniture



1. Description

Ceramic Fiber Blanket is an ideal thermal insulation , fire-proofand sound-absorbing material. The Ceramic Fiber Blanket is composed of long, flexible, interwoven fibers manufactured by the blownand the spunprocess yielding a strong, light weight, durable blanket for applications in a temperature range from 1100° C (2012° F ) to 1430° C (2600° F).The ceramic fiber blanket is completely inorganic and is needled to provide exceptional handling strength,used in a variety of heat processing applications.



2. Product Features

Low density and low thermal conductivity

Resilience and resistance to thermal shock

Excellent chemistry quality

Flexible and easy to cut or install

Aluminosilicate Refractory Material Ceramic Fiber Blanket


3. Product Application

Ceramic Fiber Blanket is widely used for industrial furnace heat treatment, direct exposure to heat as furnace hot face lining, high temperature filter material, heat treatment insulation, and expansion joints.



4. Physical & Chemical Data

Product Name Ceramic Fiber
CalssificationTemperature 1260℃ 1400℃ 1600℃
Product Code Hybz-st1000 Hygc-st1100 Hyhg-st1350 Hyyhl-st1500
Shrinkage on heating

1000℃x24h

≤-3

1100℃x24h

≤-3

1350℃x24h

≤-3

1500℃x24h

≤-3

Thermal 400℃ 0.040-0.062 0.050-0.073
Conductivity 800℃ 0.08-0.111 0.090-0.120
(W/m.k) 1200℃ 0.150-0.22 0.161-0.2103
Density(kg/m³) 96/128 128
Specification(mm) 3660/7320/14640 x 610/1220 x50/25/12.7
Tensile strength (128kg/m³) Mpa ≥0.04
Al2O3(%) ≥45 ≥45 38~40 72
ZrO2(%) - 15~17 -
Al2O3 + SiO2 (%) ≥97 ≥99 - ≥99
Al2O3 + SiO2 +ZrO2(%) - - ≥99 -
Fe2O3(%) ≤1.0 ≤0.2 ≤0.2 ≤0.2
K2O + Na2O (%) ≤0.5 ≤0.2 ≤0.2 -
Package Poly bag 20kg/bag, Carton box



Notes:

Common grade 1100ºC(2012 ° F)
Standard grade 1260ºC(2300 ° F)
High Pure grade 1260ºC (2300 ° F)
High Alumina grade 1360ºC(2480 ° F)
Zirconia grade 1430ºC(2600 ° F)



5. Package

Packaging Detail Packing:Carton or according to customer requirments
Delivery Detail: Within 30 days after receipt deposit
Shipping terms FOB Qingdao Port or CIF,CFR and more
Payment

T/T, west union,L/C. 50% deposit, 50% balance before delivery
