Product Details:
|
| Dimension: | 290*85*50mm | Color: | Yellow |
|---|---|---|---|
| Density: | 2.0g/cm3 | Feature: | High Temperature Resistance |
| Max Using Temperature: | 1250 ℃ | Material: | Cordierite |
| High Light: | kiln supports,kiln tools |
||
1. Advantages
1). Excellent insulation ,security , long working life .
2). Precise grinding and polishing.
3). Excellent heat radiation, small size ,more environmental and energy-efficient .
4). good thermal conductivity
5). large specific heat capacity
6). low pressure drop
7). good heat-shock resisting ability
8). Working temperature: <1250℃
Cordierite is one of the most popular ceramics for its properties of excellent thermal stability, high refractoriness, good chemical durability, low dielectric constant, and low thermal expansion.
Cordierite is extensively used in important industrial applications such as micro electronics, refractory products, heat exchanger for gas turbines, thermal shock-resistant table ware, catalyst supports, and porous ceramics. Low-expansion cordierite is suitable for being applied at high temperature circumstance where a good thermal shock resistance is required.This unique property of cordierite is caused by the negative lattice expansion in c-axis direction,which provides excellent resistance to thermal shock as well as low thermal conductivity.
2. Technical Parameter
| Item | Cordierite batts | |
| Apparent porosity,% | 28 | |
| Bulk density,g/cm3 | 2.0 | |
| Modulus of rupture, | 20℃ | ≥5 |
| 1250℃×0.5h | ≥3 | |
| Phase composition,% | Mullite | 55 |
| Cordierite | 30 | |
| Max. service temp. | 1280℃ | |
| Chemical composition,% | Al2O3 | 40-48 |
| SiO2 | 45-48 | |
| MgO | 5-10 | |
3. Application
Cordierite batts is widely used to sinter pottery , ceramic insulator and so on.
We can also supply SiSic beam.
